| 标准： | ASTM B163/ ASME SB163 | 材料 | UNS N04400/DIN 2.4360/MONEL 400 |
|---|---|---|---|
| 管道类型： | U 形弯管/直管无缝钢管 | 长度 | 6 米或根据需要指定长度 |
| 申请： | 热交换器，冷凝器 | 交货条件： | 退火腌制 |
| 测试： | 涡流测试，水压测试，超声波测试，硬度测试， ... | 包装 | 胶合板箱/编织袋套装 |
| 强光 | uns n04400 seamless alloy tube， sch5s seamless alloy tube， monel 400 alloy steel | ||
ASTM B163/ASME SB163 UNS N04400/DIN 2.4360/MONEL 400 NICKEL ALLOY SEAMLESS TUBE
概述：
Monel 400 is a nickel-copper alloy that offers excellent resistance to corrosion in various environments. It also provides good mechanical properties， making it suitable for use in a wide range of applications， including marine engineering， chemical processing， and aerospace.
Monel 400 seamless tubes are widely used in the chemical processing industry， where they serve as a cost-effective alternative to high-performance alloys such as Inconel and Hastelloy. The tubes have a high resistance to corrosion by seawater， chlorides， and reducing acids， making them suitable for use in marine environments.
The seamless tubes are available in different sizes， thicknesses， and lengths， and can be customized to fit specific end-user requirements. The manufacturing process ensures uniform wall thickness， high dimensional accuracy， and excellent surface finish.
Monel 400 seamless tubes also exhibit good mechanical properties， including high strength and ductility. They have excellent resistance to stress-corrosion cracking and thermal fatigue， making them ideal for use in high-stress and high-temperature applications.
The tubes also exhibit good formability and weldability， allowing them to be shaped and joined easily. Their excellent thermal conductivity and low electrical resistivity make them suitable for use in electrical and electronic components.
规格
| 规格 | ASTM B163 & Its equivalent ASME， DIN & EN Standard |
| 年级 | UNS N04400/DIN 2.4360/MONEL 400 |
| 类型 | U 形弯管和直缝无缝钢管 |
| 外径 | 1/4'' 至 2'' 或定制尺寸 |
| 壁厚 | BWG25;BWG22;BWG20;BWG18;BWG16;BWG14;BWG12;BWG10 |
| 长度 | 长达 6 米，可定制切割长度 |
| 交货条件 | 退火腌制 |
| 结束语 | 平端，斜端 |
| 其他测试 | 产品分析， 涡流试验，水压试验，超声波试验， 压平测试、硬度测试、拉伸测试等。 |
| 尺寸 | 所有管材均按照 ASTM 和 ASME 等相关标准进行生产和检验/测试 |
| 包装 | 胶合板箱/捆绑编织袋 |
化学成分
| 等级 | 倪 | 铜 | 铁 | 锰 | C | Si | S |
| UNS N04400 | 63.0 min. | 28.0-34.0 | 2.50 max. | 2.00 max. | 0.30 max. | 最大 0.50 | 0.024 max. |
机械性能
| 等级 | 拉伸强度，最小，ksi (MPa) | 屈服强度， 最小， ksi (MPa) | 2 英寸伸长率 或 50 毫米，最小值（%） |
| UNS N04400 | 70(483) | 28(193) | 35 |
应用：
1.海洋工程。
2.化工和碳氢化合物加工设备。
3.汽油箱和淡水箱。
4.原油蒸馏器。
5.除气加热器。
6.锅炉给水加热器和其他热交换器。
7.阀门、泵、轴、配件和紧固件。
8.工业热交换器。
9.氯化溶剂。
10.原油蒸馏塔。
