Stainless Steel Pipe Fittings , ASTM A182 / ASME SA182 F316L Forged Threaded Coupling

Product Details
Place of Origin: CHINA
Brand Name: TONG CHUANG
Certification: ABS, BV, DNV, LR, GL , KR, NSK, CCS, ISO, TS , PED , GOST
Model Number: Couplings : A105 / A182 / B564 / B16.11 /B16.22 , MPS-75
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Packaging Details: PLY-WOODEN CASE OR PALLET
Delivery Time: 7 DAYS
Payment Terms: L/C,T/T

SKU: 2572 Category:
Product Name:CouplingMaterial:Stainless Steel ， Nickel Alloy， Carbon Steel ， Copper And Nickel Alloy
Standard:ASTM A105， ASTM A182， ASTM B564， B16.11， B16.22Certificate:Couplings : A105 / A182 / B564 / B16.11 /B16.22 ， MPS-75
Type:ThreadedClass:150#， 300#， 600#， 900#， 1500#， 2000#， 3000#， 6000#， 9000#
Application:Off-shore Oil Drilling Companies Heat Exchangers， Condensers Power Generation Gas Processing，etc.
High Light:

Forged Threaded Coupling

，

Threaded Coupling Steel Pipe Fittings

，

Forged Coupling Steel Pipe Fittings

ASTM A182 / ASME SA182 F316L Stainless Steel Pipe Fittings Forged Threaded Coupling

We are offerings steel couplings that are designed and fabricated using qualitative grade of stainless steel and alloy steel in the production process. Our precision engineered steel couplings are widely used in various industries such as engineering， automotive， paper & print， and many more owing to the salient features such as corrosion resistance， high tensile strength and durability. We are offering these couplings at market leading prices.

Stainless steel ASTM A182 F316L Coupling is a type of stainless steel pipe coupling(COPLA)， which with socket weld type and threaded type， a pipe coupling is a type of connecting between two pipes， and there are Socket weld connecting and threaded connecting type， and also if the size is different， there would be a type of reducing couplings for pipe line project.

Material Grades

Stainless Steel

ASTM / ASME SA 312 GR. TP 304， 304L， 304H， 309S， 309H， 310S， 310H， 316， 316TI， 316H， 316LN， 317， 317L， 321， 321H， 347， 347H， 904L.



ASTM / ASME SA 358 CL 1 & CL 3 GR . 304， 304L， 304H， 309S， 309H， 310S， 310H， 316， 316H， 321， 321H， 47

Duplex Steel
ASTM / ASME SA 790 UNS NO S 31803， S 32205， S 32550， S 32750， S 32760.
Carbon Steel

ASTM / ASME A 53 GR. A & B， ASTM A 106 GR. A， B & C. API 5L GR. B， API 5L X 42， X 46， X 52， X 60， X 65 & X 70.

ASTM / ASME A 691 GR A， B & C

Alloy SteelASTM / ASME A 335 GR P 1， P 5， P 9， P 11， P 12， P 22， P 23， P 91
ASTM / ASME A 691 GR 1 CR， 1 1/4 CR， 2 1/4 CR， 5 CR， 9CR， 91
Nickel AlloyASTM / ASME SB 163 UNS 2200 ( NICKEL 200 )
ASTM / ASME SB 163 UNS 2201 (NICKEL 201 )
ASTM / ASME SB 163 / 165 UNS 4400 (MONEL 400 )
ASTM / ASME SB 464 UNS 8020 ( ALLOY 20 / 20 CB 3 )
ASTM / ASME SB 704/705 UNS 8825 INCONEL (825)
ASTM / ASME SB 167 / 517 UNS 6600 (INCONEL 600 )
ASTM / ASME SB 167 UNS 6601 ( INCONEL 601 )
ASTM / ASME SB 704 /705 UNS 6625 (INCONEL 625)
ASTM / ASME SB 619/622/626 UNS 10276 ( HASTELLOY C 276 )
Copper AlloyASTM / ASME SB 111 UNS NO. C 10100， 10200， 10300， 10800， 12000， 12200， 70600， 71500.
ASTM / ASME SB 466 UNS NO. C 70600 ( CU -NI- 90/10)， C 71500 ( CU -NI- 70/30)
Size1/8" NB TO 4" NB. (SOCKETWELD & THREADED)
Class150#， 300#， 600#， 900#， 1500#， 2000#， 3000#， 6000#， 9000#



Threaded Couplings， Reducers and Caps
Coupling (TH)Reducer (TH)Half Coupling (TH)Pipe Cap (TH)
Dimensional Data ( 1/8" to 4" class 3000 & 6000 threaded )
Class 3000　1/81/43/81/23/411 1/41 1/222 1/234
B3/43/47/81 1/81 3/81 3/42 1/42 1/233 5/84 1/45 1/2
D15/16111 1/41 7/161 5/81 3/41 3/41 7/82 3/82 9/162 11/16
　
Class 6000　1/81/43/81/23/411 1/41 1/222 1/234
B7/811 1/41 1/21 3/42 1/42 1/233 5/84 1/456 1/4
D11 1/1611 5/161 1/21 11/161 13/161 7/822 1/22 11/162 15/16

Socket Weld Couplings， Reducerss and Caps
Coupling (SW)Reducer (SW)Half Coupling (SW)Pipe Cap (SW)
Dimensional Data
Class 3000　1/81/43/81/23/411 1/41 1/222 1/234
B3/47/81 1/161 1/41 1/21 13/162 1/42 1/233 5/84 5/165 1/2
C0.4200.5550.6900.8551.0651.3301.6751.9152.4062.9063.5354.545
D7/167/167/161/29/165/811/163/47/87/811 1/8
F11/163/43/47/811 1/161 3/161 1/41 1/21 9/161 13/162 1/16
　
Class 6000　1/81/43/81/23/411 1/41 1/222 1/234
B–––1 1/21 3/42 1/42 1/233 5/84 1/456 1/4
C–––0.8551.0651.3301.6751.9152.4062.9063.5354.545
D–––1/29/165/811/163/47/87/811 1/8
F–––11 1/161 1/41 5/161 3/81 5/81 11/161 15/162 5/16



316L Stainless Seel Benefits
  • 1. Corrosion resistance Fire and heat resistance
  • 2. Hygiene
  • 3. Aesthetic appearance
  • 4. Strength-to-weight advantage
  • 5. Ease of fabrication
  • 6. Impact resistance
  • 7. Long term value
  • 8. Sustainability

Stainless Steel 316L Forged Fittings Application Industries

  • Off-shore Oil Drilling Companies
  • Heat Exchangers， Condensers
  • Power Generation
  • Gas Processing
  • Pulp and Paper Industry
  • Chemical Equipment
  • Sea Water Equipment
  • Pharmaceuticals
