ASTM B165 UNS N04400 MONEL 400 Nickel Copper Alloy for Gas Processing

Product Details
Place of Origin: CHINA
Brand Name: TONG CHUANG SPECIAL STEEL
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM B165 UNS N04400 MONEL 400 NICKE-COPPER ALLOY
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 20-80
Payment Terms: L/C, T/T

SKU: 1923 Category:
Standard:ASTM B165Material:UNS NO4400
Specification:ASTM B165 UNS N04400 MONEL 400 NICKE-COPPER ALLOYApplication:Heating Element
Type:Nickel PipeSize:Customer Made
Density:8.83 G/cm3Surface:Bright
Packaging Details:Monel Pipe Are Pqacked In Cartoon Boxes. Special Packaging Requirements Can Also Be Accommodated. OEM Is Also Acceptable.Shape:Round.square.Rectangle.
High Light:

ASTM B165 alloy

，

monel 400 alloy

，

Nickel Copper Alloy

ASTM B165 UNS N04400 MONEL 400 Nickel Copper Alloy for Gas Processing

We are TONG CHUANG GROUP， one of the biggest manufactures of stainless steel & duplex steel & alloy steel tubes and pipes in China. With development more than 20 years， we have accumulated a great many clients all around the world and TONG CHUANG products also won the great praise among the customers.



Description:

Monel 400 is copper nickel alloy，has good corrosion resistance. In salty water or seawater has excellent resistance to pitting corrosion， stress corrosion ability. Especially hydrofluoric acid resistance and resistance to the hydrochloric acid. Widely used in the chemical， oil， Marine industry.

It is widely used on many aspects， like valve and pump parts， electronic components， chemical processing equipment， gasoline and freshwater tanks， petroleum processing equipment， propeller shafts， marine fixtures and fasteners，boiler feedwater heaters and other heat exchangers.



Chemical Composition of ASTM B165 UNS N04400

ElementContent， %
Nickel [Ni]≥63.0
Copper [Cu]28.0~34.0
Iron [Fe]≤2.50
Manganese [Mn]≤2.00
Carbon [C]≤0.30
Silicon [Si]≤0.50
Sulfur [S]≤0.024





Mechanical Properties of ASTM B165 UNS N04400

Condition & Size

Tensile Strength， min.

Yield Strength， min.

Elongation，

ksi [MPa]

ksi [MPa]

min. %

*A

70 [480]

28 [195]

35

*B

70 [480]

25 [170]

35

*C

85 [585]

55 [380]

15



Condition & Finish

The or tube manufactured to ASTM B165 shall be furnished in annealed or stress-relieved condition. The surface of annealed pipe or tube is soft， with a dull matte finish. The stress relieving refers to thermally treated below the annealing temperature to relieve the major portion of the internal stresses. It will be furnished with a thin， light- to medium- dark surface.



ASTM B165 & Tubes Application Industries

  • Off-Shore Oil Drilling Companies
  • Power Generation
  • Petrochemicals
  • Gas Processing
  • Specialty Chemicals
  • Pharmaceuticals
  • Pharmaceutical Equipment
  • Chemical Equipment
  • Sea Water Equipment
  • Heat Exchangers

  • Condensers

  • Pulp and Paper Industry

ASTM B165 Pipe and Tube Test Certificates



We at GIC provide Manufacturer TC (Test Certificate) in accordance to EN 10204/3.1B， Raw Materials Certificate， 100% Radiography Test Report， Third Party Inspection Report. We also provide Standard certificates like EN 10204 3.1 and additional requirement like. NACE MR 01075. FERRIT CONTENT as per norms if requested by clients.

  • EN 10204/3.1B，
  • Raw Materials Certificate
  • 100% Radiography Test Report
  • Third Party Inspection Report， etc

Material Testing:

  • Mechanical Testing Such as Tensile of Area

  • Hardness Test

  • Chemical Analysis – Spectro Analysis

  • Positive Material Identification – PMI Testing

  • Flattening Test

  • Micro and MacroTest

  • Pitting Resistance Test

  • Flaring Test

  • Intergranular Corrosion (IGC) Test
