| Material Grade: | TP304H ， TP310H， TP316H， TP321H， TP347H | Certificate: | LR， BV， DNV， GL， ABS， KR， CCS， TS， PED， AD2000， ASME II ， III， |
|---|---|---|---|
| Standard: | NACE 0175 ， ASTM A312， GOST9941-81， DN17456， EN10216-5 | TYPE: | SEAMLESS ， WELDED |
| Application: | High Temperature ， Boiler ， Heat Exchanger ， Petrochemical | NDT: | ET， UT， HT， PT |
| High Light: | TP321H Stainless Steel， TP316H Stainless Steel， ASTM A312 Stainless Steel | ||
ASTM A312 TP304H TP310H TP316H TP321H TP347H Stainless Steel
TONG CHUANG GROUP ASTM A312 seamless stainless tube， ASTM A312 welded seamless stainless tubes， ASTM A312 seamless stainless pipes， ASTM A312 welded seamless stainless pipes， TP304 TP304L TP304H stainless pipes， TP309S TP309H stainless pipes， TP310S TP310H stainless pipes， TP316 TP316L stainless pipes. TP321 TP321H stainless pipe， TP347 TP347H stainless pipe， seamless stainless pipe， welded stainless pipe， seamless stainless tube， welded stainless tube， Seamless Stainless-Steel Pipe
ANSI B16.10: B16.19 SCH 5S， SCH 10S， SCH 20， SCH 30， SCH 40S， SCH 60， SCH80S， XS， SCH 100， SCH 120， SCH160， XXS
Chemical Composition
| Grade | UNS Design | Composition， % | ||||||||||||||
| C | Mn | P | S | Si | Cr | Ni | Mb | Ti | Nb | N | Cu | Ce | B | Al | ||
| TP304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0–20 | 8.0–11 | . . . | . . . | . . . | . . . | . . . | . . . | ||
| TP304L | S30403 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0–20 | 8.0–13 | . . . | . . . | . . . | . . . | . . . | . . . | ||
| TP304H | S30409 | 0.04 – 0.1 | 2 | 0.045 | 0.03 | 1 | 18.0–20 | 8.0–11 | . . . | . . . | . . . | . . . | . . . | . . . | ||
| TP310S | S31008 | 0.08 | 2 | 0.045 | 0.03 | 1 | 24.0- 26 | 19.0- 22 | 0.8 | . . . | . . . | . . . | . . . | . . . | ||
| TP310H | S31009 | 0.04 – 0.1 | 2 | 0.045 | 0.03 | 1 | 24.0–26 | 19.0–22 | . . . | . . . | . . . | . . . | . . . | |||
| TP310H | S31035 | 0.04 – 0.1 | 0.6 | 0.025 | 0.015 | 0.4 | 21.5–23.5 | 23.5–26.5 | . . . | . . . | 0.40- 0.6 | 0.20- 0.3 | 2.5- 3.5 | . . . | 0.002- 0.008 | |
| TP316 | S31600 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0–18 | 10.0–14 | 2.00–3 | . . . | . . . | . . . | . . . | . . . | ||
| TP316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0–18 | 10.0–14 | 2.00–3 | . . . | . . . | . . . | . . . | . . . | ||
| TP316H | S31609 | 0.04 – 0.1 | 2 | 0.045 | 0.03 | 1 | 16.0–18 | 10.0–14 | 2.00–3 | . . . | . . . | . . . | . . . | . . . | ||
| TP317 | S31700 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0–20 | 11.0–15 | 3.0–4 | . . . | . . . | . . . | . . . | . . . | ||
| TP317L | S31703 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0–20 | 11.0–15 | 3.0–4 | . . . | . . . | . . . | . . . | . . . | ||
| TP321 | S32100 | 0.08 | 2 | 0.045 | 0.03 | 1 | 17.0–19 | 9.0–12 | . . . | Ti 5 × (C+N) min， 0.70 max | . . . | 0.1 | . . . | . . . | ||
| TP321H | S32109 | 0.04 – 0.1 | 2 | 0.045 | 0.03 | 1 | 17.0–19 | 9.0–12 | . . . | 4(C+N) min; 0.70 max | . . . | 0.1 | . . . | . . . | ||
| TP321H | S32654 | 0.02 | 2.0-4 | 0.03 | 0.005 | 0.5 | 24.0–25 | 21.0–23 | 7.0-8 | . . . | . . . | 0.45- 0.55 | 0.30-0.6 | . . . | ||
| TP321H | S33228 | 0.04 – 0.08 | 1 | 0.02 | 0.015 | 0.3 | 26.0–28 | 31.0–33 | . . . | . . . | 0.60- 1 | . . . | . . . | 0.05 – 0.1 | 0.025 | |
| TP321H | S34565 | 0.03 | 5.0-7 | 0.03 | 0.01 | 1 | 23.0–25 | 16.0–18 | 4.0-5 | . . . | 0.1 | 0.40- 0.6 | . . . | . . . | ||
| TP347 | S34700 | 0.08 | 2 | 0.045 | 0.03 | 1 | 17.0–19 | 9.0–13 | . . . | . . . | See Spec | . . . | . . . | . . . | ||
| TP347H | S34709 | 0.04 – 0.1 | 2 | 0.045 | 0.03 | 1 | 17.0–19 | 9.0–13 | . . . | . . . | See Spec | . . . | . . . | . . . | ||
| Alloy 20 | N08020 | 0.07 | 2 | 0.045 | 0.035 | 1 | 19.0–21 | 32.0–38 | 2.0–3 | . . . | See Spec | . . . | 3.0– 4 | . . . | . . . | . . . |
| Alloy 20 | N08367 | 0.03 | 2 | 0.04 | 0.03 | 1 | 20.0–22 | 23.5–25.5 | 6.0–7 | . . . | . . . | 0.18–0.25 | 0.75 | . . . | . . . | . . . |
| Alloy 20 | N08028 | 0.03 | 2.5 | 0.03 | 0.03 | 1 | 26.0–28 | 30.0–34 | 3.0–4 | 0.60–1.4 | ||||||
| Alloy 20 | N08029 | 0.02 | 2 | 0.025 | 0.015 | 0.6 | 26.0–28 | 30.0–34 | 4.0–5 | 0.6– 1.4 | ||||||
Final Finishing:
Solution Annealed & Pickled
Supplementary Testing : Apart from the above mentioned tests， we also carry out on the manufactured products supplementary testing. The tests conducted under this include:
|
|
|
Application
- Food processing equipment， especially beer brewing， milk processing and wine making equipment.
- Kitchen worktops， sinks， troughs， equipment and utensils
- Architectural paneling， railings and trimmings
- Chemical containers， including transportation containers
- Heat exchangers
- Woven or welded screens for mining， quarrying and water filtration
- Threaded fasteners
- Springs
