| Product Name: | Stainless Steel Seamless Tube | Standard: | ASTM A268， ASME SA268 |
|---|---|---|---|
| Material: | TP409/TP410/TP405/TP420/TP430/TP430Ti/TP403/TP444/TP439/TP446，etc | Type: | Seamless， Welded |
| Surface: | Polished， Bright Annealed， Picked And Annealed | End: | Beveled End， Plain End |
| Technique: | Cold Drawn， Cold Rolled， Extrusion， Hot Rolled Tube | Application: | Heat Exchanger， Heater， Condenser， Machining， Bearing Machining， API Service |
| Package: | Plywood Case /Iron Case/ Bundle With Plastic Cap/requirements | Highlight: | ASTM A268 TP410 Stainless Steel Seamless Tube |
ASTM A268 TP410 / UNS S41000 / EN 1.4006 Ferritic Stainless Steel Seamless Tube
Ferritic stainless steel is magnetic in nature， unlike other types of stainless steel such as austenitic stainless steel. Ferritic stainless steel has a lower nickel content compared to other types of stainless steel， which makes it more cost-effective.
Ferritic Stainless Steel grade 410 is a general-purpose stainless steel that contains 11.5% chromium. It is magnetic in nature and has good corrosion resistance properties. Seamless tubes made from this grade of steel are commonly used in applications that require high-temperature resistance and moderate corrosion resistance.
ASTM A268 TP410 Stainless Steel Seamless Tube Specification
| Outside Diameter | 6-203mm |
| Wall Thickness | 0.5-25mm |
| Length | Up to 25m |
| Standard | ASTM A268， ASME SA268 |
| Grade | TP410/TP405/TP420/TP430/TP430Ti/TP403/TP409/TP444/TP439/TP446，etc. |
| Delivery Condition | Pickled， Polished， Bright Annealed |
| Technique | Seamless/Welded |
| Application | Heat Exchanger， Heater， Condenser， Machining， Bearing Machining， API Service… |
| Marking | Standard， Grade， Size， Heat Number， Lot Number … |
| Package | Bundle with plastic Cap， Plywood case， or as per customer's requirement. |
| Quality Requirement | Mill Test Certificate (EN 10204/3.1); 3.2， Third Part Inspection is acceptable. |
ASTM A268 TP410 Stainless Steel Tube Equivalent Grades
| Grade | UNS No | Euronorm | Swedish | Japanese | ||
| No | Name | SS | JIS | |||
| 410 | S41000 | 1.4006 | X12Cr13 | – | SUS410 | |
ASTM A268 TP410 Stainless Steel Tube Chemical compositions
| Grade | C | Si | Mn | P | S | Cr | Ni | N |
| TP410， UNS S41000 | 0.15 max | 1.00 max | 1.00 max | 0.040 max | 0.030 max | 11.5~13.5 | – | – |
ASTM A268 TP410 Stainless Steel Tube Mechanical properities
Tensile strength (MPa) min. | Yield strength (MPa) min. | Elongation (%)min. | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | |||
| 415 | 205 | 20 | 95 | 207 |
Other Material Grades
American Standard | Austenitic Steel: TP304，TP304L，TP304H， TP304N， TP310S，TP316，TP316L，TP316Ti，TP316H， TP317，TP317L， TP321， TP321H，TP347， TP347H，904L… Duplex Steel : S32101，S32205，S31803，S32304，S32750， S32760 Others:TP405，TP409， TP410， TP430， TP439，… |
Europen Standard | 1.4301，1.4307，1.4948，1.4541，1.4878，1.4550，1.4401，1.4404，1.4571，1.4438， 1.4841，1.4845，1.4539，1.4162， 1.4462， 1.4362， 1.4410， 1.4501 |
GOST | 08Х17Т，08Х13，12Х13，12Х17，15Х25Т，04Х18Н10，08Х20Н14С2， 08Х18Н12Б，10Х17Н13М2Т，10Х23Н18，08Х18Н10，08Х18Н10Т， 08Х18Н12Т，08Х17Н15М3Т，12Х18Н10Т，12Х18Н12Т，12Х18Н9， 17Х18Н9， 08Х22Н6Т， 06ХН28МДТ |
Applications
1. Off-Shore Oil Drilling Companies
2. Power Generation
3. Petrochemicals
4. Gas Processing
5. Specialty Chemicals
6. Pharmaceutical Equipment
7. Sea Water Equipment
8. Heat Exchangers
9. Condensers
10. Pulp & Paper Industry
