| Standard: | ASTM B163 / ASME SB163 | Material Grade: | ASTM B163 / ASME SB163 |
|---|---|---|---|
| Technique: | Hot Rolled，Cold Drawn | Thickness: | 1 – 30 Mm |
| Outer Diameter(round): | 10 – 2000 Mm | Alloy Or Not: | Is Alloy |
| Length: | 1m-12m | Application: | Boiler Pipe，Structure Pipe，Oil Pipe，Chemical Fertilizer Pipe，Fluid Pipe |
ASME SB163 N06600 Nickel Alloy Steel SMLS Tube
Alloy 600 is an excellent candidate for many uses in extremely high temperature and highly corrosive environments. The blend of nickel and chromium yields a solid resistance to oxidation in operating temperatures. These temperatures can range from cryogenic to scorching levels of 2，000°F. The high nickel content of alloy 400 also offers a nearly-complete resistance to stress corrosion cracking， which is commonly found in chloride environments.
Chemical Composition:
| Ni | 72.0 min |
| Cu | 0.50 max |
| Fe | 6.00–10.00 |
| Mn | 6.00–10.00 |
| C | 0.15 max |
| Si | 0.50 max |
| S | 0.015 max |
| Cr | 14.0–17.0 |
Nickel 600 Seamless Tube Mechanical Behaviour:
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80，000 ， MPa – 550 | Psi – 30，000 ， MPa – 205 | 30% |
Standard Specification for Seeamless Nickel and Nickel Alloy Condenser and Heat-Exchanger Tubes
ASME SB165 Standard Specification for Nickel-Copper Alloy (UNS N04400)* and Tube
ASME SB167 Standard Specification for Nickel-Chromium-Iron Alloys， Nickel-Chromium-Cobalt-Molybdenum Alloy (UNS N06617)，and Nickel-Iron-Chromium-Tungsten Alloy (UNS N06674) and Tube
ASME SB407 Standard Specification for Nickel-Iron-Chromium Alloy and Tube
ASME SB423 Standard Specification for Nickel-Iron-Chromium-Molybdenum-Copper Alloy (UNS N08825， N08221， and N06845) and Tube
ASME SB444 Standard Specification for Nickel-Chromium-Molybdenum-Columbium Alloys (UNS N06625 and UNS N06852) and Nickel-Chromium-Molybdenum-Silicon Alloy (UNS N06219) Pipe and Tube
ASME SB622 Standard Specification for Seamless Nickel and Nickel-Cobalt Alloy Pipe and Tube
ASME SB668 UNS N08028 and Tube
ASME SB690 Standard Specification for Iron-Nickel-Chromium-Molybdenum Alloys (UNS N08366 and UNS N08367) and Tube
ASME SB729 Standard Specification for seamless UNS N08020， UNS N08026， and UNS N08024 nickel alloy pipe and Tube
